Eye Operating Table OT 15

Eye Operating Table OT 15

The OT 15 Ophthalmic Operation Table is a motorized height-adjustable surgical table designed for eye surgeries and precision medical procedures.
Specification :
  •  Height: Motorized adjustment
  • Headrest: Adjustable
  • Leg Space: Spacious design
  •  Material: Anti-static cushioned platform
  •  Positioning: Manual Trendelenburg & Reverse
The Ophthalmic Operation Table – OT 15 is a state-of-the-art surgical platform designed to provide precision, comfort, and flexibility during ophthalmic surgeries. Featuring a motorized height adjustment system, surgeons can operate while sitting or standing for optimal ergonomic positioning.   The adjustable headrest allows for customizable patient positioning, ensuring maximum comfort and stability. With ample leg space beneath the platform, surgeons can conveniently position their foot pedals and medical instruments.   Crafted from high-quality anti-static polyurethane material, the cushioned operating surface offers exceptional support and hygiene standards. The manual Trendelenburg & reverse Trendelenburg functions enable seamless adjustments for improved surgical access.
  • Platform Height: Motorized height adjustment for sitting/standing operations
  • Headrest: Adjustable for optimal patient positioning
  • Leg Space: Spacious area beneath the table for pedal and equipment placement
  • Material: Anti-static polyurethane cushioned platform for patient comfort
  • Positioning: Manual Trendelenburg & Reverse Trendelenburg.
Technical Specifications:

1. Height Range (Min/Max):

640 mm (25″) / 850 mm (33″)

2. Lifting Speed:

8 mm/sec

3. Maximum Load Capacity:

180 KG

4. Sleeping Bed Tilting:

30 Degrees

5. Bed Length:

1900 mm (74.5″)

6. Bed Width:

610 mm (24″)

7. Base Size:

880 mm (35″) / 480 mm (19″)

8. Power Supply:

AC 230V / 110V, 50/60 Hz

9. Gross Weight:

95 KG

10. Optional:

Castors

  • Adjust the Table Height: Use the motorized control to set the ideal working height.
  • Position the Headrest: Modify the adjustable headrest to match the patient’s needs.
  • Utilize the Leg Space: Place surgical equipment and foot pedals comfortably beneath the table.
  • Trendelenburg Adjustments: Manually tilt the Trendelenburg positions for better patient positioning.
  • Post-Use Maintenance: Wipe down the anti-static surface with hospital-grade disinfectants.
